Napofix® VWA1300G-M – TV Motorized Floor Cart Mount

Product info

• Product description

  • Napofix® VWA1300G-M TV Motorized Floor Cart Mount: Unlimited Mobility and Interactivity



    The Napofix® VWA1300G-M TV Motorized Floor Cart Mount is the ultimate solution for those who demand flexibility, power, and interactivity when using large screens. Ideal for dynamic environments such as collaborative offices, modern classrooms, or hospitality conference centers, this stand combines total mobility with robust, motorized height adjustment.



    Power and Precision for Large Format Screens

    Equipped with a powerful motor, this cart safely and smoothly supports and adjusts even the heaviest interactive screens, from 60 to 110 inches and with a maximum weight of 120 kg. Its broad VESA compatibility (from 100x100 to 1200x600) ensures it can be mounted to the vast majority of screens on the market.



    Motorized Height Adjustment for Every Occasion

    With a simple touch, the screen height adjusts perfectly between 1307mm and 1607mm. This control can be done through the integrated panel or with the 2-Memory RF Remote Control (Napofix® RFC001), which allows you to save your preferred heights. This feature is essential for:

    ● Collaborative Meetings and Brainstorming: Lower the interactive screen so the entire team can write and draw comfortably. Then raise it for a clear presentation to everyone in the room.

    ● Inclusive Education: Adapt the height of the digital whiteboard so that students of different ages and heights, as well as teachers, can interact with the content in an ergonomic and participatory way.

    ● Professional Video Conferencing: Position the camera (installed on the optional shelf) at eye level for participants, whether seated or standing, to create a more natural and engaging call experience.



    Mobility and Stability in Any Space

    True versatility comes from its mobility. The four heavy-duty lockable casters allow you to effortlessly move the display between meeting rooms, classrooms, or different areas of an event. Once in place, the locking brakes ensure maximum stability, allowing for secure interaction even with touchscreens.



    Adaptable Configuration to Your Needs

    To optimize the user experience, the stand includes a practical shelf with a capacity of up to 3kg, perfect for accommodating a laptop, keyboard, or other essential devices during a presentation or class.

• Compatibilities
  • Minimum screen size: 60"
  • Maximun screen size: 110"
  • VESA Minimum: 100 x 100 mm
  • VESA Maximum: 1200 x 600 mm
  • Vesa: 100 x 100 mm, 100 x 200 mm, 100 x 300 mm, 100 x 400 mm, 100 x 500 mm, 100 x 600 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 200 x 500 mm, 200 x 600 mm, 300 x 100 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 300 x 500 mm, 300 x 600 mm, 400 x 100 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 400 x 500 mm, 400 x 600 mm, 500 x 100 mm, 500 x 200 mm, 500 x 300 mm, 500 x 400 mm, 500 x 500 mm, 500 x 600 mm, 600 x 100 mm, 600 x 200 mm, 600 x 300 mm, 600 x 400 mm, 600 x 500 mm, 600 x 600 mm, 700 x 100 mm, 700 x 200 mm, 700 x 300 mm, 700 x 400 mm, 700 x 500 mm, 700 x 600 mm, 800 x 100 mm, 800 x 200 mm, 800 x 300 mm, 800 x 400 mm, 800 x 500 mm, 800 x 600 mm, 900 x 100 mm, 900 x 200 mm, 900 x 300 mm, 900 x 400 mm, 900 x 500 mm, 900 x 600 mm, 1000 x 100 mm, 1000 x 200 mm, 1000 x 300 mm, 1000 x 400 mm, 1000 x 500 mm, 1000 x 600 mm, 1100 x 100 mm, 1100 x 200 mm, 1100 x 300 mm, 1100 x 400 mm, 1100 x 500 mm, 1100 x 600 mm, 1200 x 100 mm, 1200 x 200 mm, 1200 x 300 mm, 1200 x 400 mm, 1200 x 500 mm, 1200 x 600 mm
  • Load capacity: 120 Kg
• Adjustments
  • Height adjustment: 1307~1607 mm
• Features
  • Warranty: 3 years
  • Wheels: 4 (4BW)
  • Detachable VESA: Yes
  • Shelf and Tray: 1x AV (3Kg)
  • Strapes: -
  • Angled Ceiling: -
  • Finishing: Epoxy
  • Main color: Grey
• Logistics

  Logistic data

  • • Box type: Brown box
    • Number of unit boxes: 1

  Box 1

  • • Width: 141.0 cm
    • Depth: 24.5 cm
    • Height: 20.0 cm
    • Gross weight: 27.10 kg
    • Net weight: 24.50 kg

  Box 2

  • • Width: - cm
    • Depth: - cm
    • Height: - cm
    • Gross weight: - kg
    • Net weight: - kg

  Master Box

  • • Type of master box: -
    • Number of unit boxes: -
    • Width: - cm
    • Depth: - cm
    • Height: - cm
    • Gross Weight: - kg
    • Net Weight: - kg
• Downloads
  • Technical Datasheet
  • User Manual
